可調節單路單向溫控，控溫精度0.1度
可調節電流，以調節功率
延時，過熱，限流保護
可分別顯示電流，熱敏電阻值
寬范圍電壓輸入(100-265V)
| 波長Wavelength (nm) | 473 | 功率穩定性Power Stability (RMS, over 8 hours) | <5% | |||
| 輸出功率 Output Power (mW) | 1~100 | 振幅穩定性Noise of Amplitude (P-P) | <30% | |||
| 工作方式 Working Mode | CW | 出光孔高度 Aperture Position (mm) | 30 | |||
| 光斑模式 Beam Mode | 橫模 Transverse | TEM00 | 激光器 Laser Head | 尺寸 Dimensions (L×W×H, mm) | 116 x 50 x 45 | |
| 縱模 Longitude | Multi-longitude | 重量 Net Weight (kg) | 0.5 | |||
| 線寬Spectral Linewidth (nm) | <0.1 | 可配電源型號 Integrated Driver Model | VD-I Series / VD-II Series | |||
| 偏振方式 Polarization | Line polarization | 電源調制External Modulation | 5V TTL / 5V Analogue | |||
| 偏振比Polarization Ratio | >100:1 | 調制速率Modulating Repetition | 30KHz TTL / 10KHz Analogue | |||
| 光束質量Beam Quality (M2 factor) | <2 | 制冷方式Cooling System | TEC | |||
| 光束發散角Beam Divergence (full angle, mrad) | 1.2±0.2 | 預熱時間Warm-up Time (minutes) | <15 | |||
| 光束直徑Beam Diameter at Aperture (mm) | 1.2±0.2 | 工作溫度Operation Temperature (℃) | 18~30 | |||
| 光束橢圓度 Beam Roundness | >90% | 使用壽命Expected Lifetime (hours) | >10000 | |||
| 保修期Warranty Time | 1 year | |||||
